Brand

NEXSTA

Wide View Sliding

Bring You Closer to Nature.
The Largest Opening in the Series with Easy and Smooth Operation.

Landed House
Apartment

Price Range : For Luxury Class

Video

Overview

With slim and round profiles, Wide View Sliding fulfills the functional needs of the most comfortable living space.

Basic Performance

Structural (Wind Load)

Square 1600 Pa
Deflaction L/125 and L/175

Round 500 Pa
Deflection L/125
Water Tightness

Square 300 Pa
Round 75 Pa
Sound Insulation

T-1 (-25 dB) (JIS)
T-2 (-30 dB) (JIS)
Rw 24 -30 (ISO)
Air Infiltration

Grade A-4 (JIS)
Double Glazing

Max 6 + A6 + 6 mm
Glass Groove : 22 mm

Features

Round Stile

Maximum Size for 4 Leaf is H4000×W8000 (mm).

Square Stile

Maximum Size for 4 Leaf is H3000×W6000 (mm).

Slim and Round Stile (Round type)

The stile shape is round and comfortable to open and close.

Multipoint Lock (Round type)

Multipoint lock System With Single Motion.

Variation

Wide View Sliding 2 Leaves
Wide View Sliding 3 Leaves
Wide View Sliding 4 Leaves
Wide View Sliding 6 Leaves
(Square type only)

Color Variation

YKK AP products are available in variety of finishes and colors.

* Color may vary from the original, please kindly check the actual color sample.

Finishing Color

We have three type of surface coating, Anodize, Anodize Plus and Powder Coating.
General Anodize is normal type of anodized color as most popular method in Indonesia.
Anodize Plus is our special technical method, and its durability and appearance are much better than other anodized method. Powder coating can be used for various colors.

Anodized: Anodized (General anodizing with sealing)

Anodized Plus (YKK AP Special Coating)
(anodizing with Electro Deposition)
Powder Coating: Powder Coating (Thickness minimum powder coating 50 μm)

Color Variation (Standard Colors)

Standard colors are our recommended colors. We have decided these colors based on our experience, and they can easily match with any color coordinate.

Finishing Color	White / Ivory	Light Gray / Champagne	Deep Gray	Brown	Black
Anodized Plus Fitting for Exterior Resistant to rain and UV
Powder Coating Fitting for Interior Re-paint OK

* Color may vary from the original, please kindly check the actual color sample

Lead Time Production

Standard colors have advantage in delivery time.

*Delivery times vary by region as the above does not include delivery.
*This lead time is from producing at AP until delivering to AP distributors.
Please contact each distributor for the final delivery time.

Standard Colors
Performance Goods	38-45 days

Other Colors
Performance Goods	46 days ~

New Colors
Performance Goods	46 days ~

	Standard Colors	Other Colors	New Colors
Performance Goods	38-45 days	46 days ~

Repairing Tools

Touch Up Spray

It can be used to repair scratches on surfaces quickly.
Touch Up Pen

Quick-dry and easy-to-use pen type, especially for repairing scratched surfaces.
